Vicarb V20 Lip Seal Gasket Heat Exchanger Plate Replacement

DESCRIPTION

The Vicarb V20 gasket is a solid replacement option if you’re working on Vicarb plate heat exchangers. It’s made from NBR, EPDM, or Viton depending on what you need—and does a good job sealing up leaks, resisting chemicals, and lasting a long time across different heat transfer jobs. If you’re replacing gaskets or plates on a Vicarb unit, the V20 helps keep the thermal performance where it should be, while cutting down on leaks and maintenance costs.

At SENOVIS, we supply V20 gaskets and plates that are fully compatible with Vicarb systems, meant for aftermarket repairs, servicing, or full refurbishments. You’ll see these parts used a lot in HVAC, marine, food processing, power plants, and industrial cooling. Our replacement parts are made to match the original specs, so installation is straightforward and they run reliably.

And it’s not just the V20. We also carry replacement gaskets and plate spares for other Vicarb V Series models like V2, V4, V8, V13, V28, V45, V60, V85, and V110. Helps people get more life out of their equipment and keep the heat exchanger running at its best.

Vicarb V20 Plate heat exchanger specification

Vicarb PHE Plate Heat Exchanger Replacemnet	Vicarb V20
Corrugation Depth(mm)	3.5
Port Diameter(mm)	φ70
Chevron Angle	51°120°
Corrugation Pitch(mm)	11
Equivalent Diameter	7
Flow Area(m²)	0.00073
One Plate (m²)	0.2
Port Distance (mm)	875*130
Dimensions (mm)	989*241

Actual Product Details

Suitable for HVAC, Marine, Food and Industrial Applications

The Vicarb V2 heat exchanger gasket is widely used in plate heat exchanger maintenance, refurbishment, and replacement projects across various industries.

HVAC Industry

Used in heating, ventilation, and air conditioning systems for heat transfer in chillers, district cooling networks, boilers, and building services.

Marine Industry

Applied in marine cooling, central cooling units, freshwater generators, lubricating oil coolers, and engine heat exchangers operating in demanding offshore and shipboard environments.

Food Industry

Suitable for plate heat exchangers used in dairy processing, beverage production, brewing, pasteurization, and other hygienic heat transfer applications requiring dependable sealing performance.

Oil and Gas Industry

Used in upstream, midstream, and downstream operations, including process cooling, lubrication systems, hydraulic oil cooling, and heat recovery within oil and gas facilities.

The Vicarb V2 gasket helps maintain operation of PHE systems while supporting routine maintenance and spare parts replacement.
