Tranter GXD-060 gasket for Tranter Heat Exchanger sealing and replacement applications. — Replacement sealing solution for Tranter Heat Exchanger Gaskets servicing requirements.

Tranter GXD 060 UFX60 Gasket PHE Type Heat Exchanger Spare Parts

The Tranter GXD 060 Gaskets are direct replacements for the Tranter GXD-060 PHE — also referenced as GXD060 / UFX60 across service documentation.

The Tranter Plate And Frame Heat Exchanger format means plates and gaskets are fully replaceable without pulling the unit — which is why the Tranter Plate Type Heat Exchanger remains a common choice in industrial heating, cooling and process applications.

Tranter GXD060 UFX60 Heat Exchanger Plate and Gaskets and Plates for Tranter Plate Heat Exchangers stocked in NBR, EPDM and FKM for repair and refurbishment.

Tranter GXD 060 Gasket details

PHE Model

Tranter GXD 060 Gasket

Keyword

Compatible PHE Spare Parts Factory

Applicable Industries

Chemical, HVAC, Power, Sugar, Beverage, Refinery, Marine, Paper,Oil and Gas, Food Industry

Compatible Brands

GXD060 / UFX60

Connection Type

Clip-on/ Glue/ Glueless

Gasket material

EPDM, NBR, HNBER, HEPDM,FKW

Selling Units

Single item

Certificate

ISO9001,ISO14001,NSF61, KTW, W270, ACS, AS4020, WRAS, EN681, EN549, ROHS, REACH,IATF 16949

DESCRIPTION

The Tranter GXD 060 Gaskets are direct replacement sealing components for the Tranter GXD-060 plate heat exchanger, also identified as GXD060 / UFX60 in spare parts documentation — two references for the same frame that come up interchangeably depending on which generation of service records you’re working from.
The Tranter Plate And Frame Heat Exchanger design is what makes the GXD-060 straightforward to service — removable plates and gaskets mean worn components can be swapped out without pulling the whole unit. That’s the practical reason the Tranter Plate Type Heat Exchanger format remains common in industrial heating, cooling and process applications where regular maintenance access matters.
Tranter GXD060 UFX60 Heat Exchanger Plate and Gaskets and Plates for Tranter Plate Heat Exchangers are available for the GXD-060 frame in NBR, EPDM and FKM, selected according to operating media and service conditions. Tranter GXD-060 Gaskets and Plates cover both gasket renewal and full plate replacement for refurbishment projects.
Tranter PHE Ab replacement solutions and Tranter Plate Heat Exchanger spare parts are supplied for global aftermarket maintenance requirements across the GXD series.

Tranter GXD 060 Gasket Replacement Specification

PHE Model	Tranter GXD 060 Evaporator Gasket
Applicable Industries	Chemical, HVAC, Power, Sugar, Beverage, Refinery, Marine, Paper
Compatible Brands	Alfa Laval, GEA, Sondex, Tranter, APV, Kelvion, etc.
Connection Type	Clip on/ Glueless/ Glued
Gasket material	NBR,FKM, HNBR, ACM,Silicone,EPDM
Color	Black/White
Temperature Range(°C)	-15~180℃
Keyword	NBR Gasket Supplier
Certificate	ISO / CE
Service	Professional technical support for model selection and installation
Design Pressure	0.6MPa~5MPa

Tranter GXD 060 Plate heat exchanger specification

PHE Plate Heat Exchanger Replacemnet	Tranter GXD 060
Corrugation Depth(mm)	3.5
Port Diameter(mm)	φ194
Chevron Angle	85°115°
Corrugation Pitch(mm)	12
Equivalent Diameter	7
Flow Area(m²)	0.00228
One Plate (m²)	0.6
Port Distance (mm)	*910420**
Dimensions (mm)	*1196704**

Tranter phe Model Cross-Reference

Current Model	Legacy / Earlier Model Name	Common Old-System Naming	New-System / Official Naming	Hyphen-Free Naming
Tranter GC008	GC-008	GC-008 / GC008	GCD-008	GCD008
Tranter GC16	GC-16	GC-16 / GC16	GCD-016 / GCP-016	GCD016 / GCP016
Tranter GL13	GL-13	GL-13 / GL13	GLD-013 / GLP-013	GLD013 / GLP013
Tranter GX12	UFX-12	UFX-12 / GX-12 / GX12	GXD-012	GXD012
Tranter GX18	UFX-18	UFX-18 / GX-18 / GX18	GXD-018	GXD018
Tranter GX26	UFX-26	UFX-26 / GX-26 / GX26	GXD-026	GXD026
Tranter GX42	UFX-42	UFX-42 / GX-42 / GX42	GXD-042	GXD042
Tranter GC26	GC-26	GC-26 / GC26	GCP-026	GCP026
Tranter GX51	UFX-51	UFX-51 / GX-51 / GX51	GXD-051	GXD051
Tranter GC51	GC-51	GC-51 / GC51	GCP-051	GCP051
Tranter GC54	GC-54	GC-54 / GC54	GCD-054*	GCD054
Tranter GX64	UFX-64	UFX-64 / GX-64 / GX64	GXD-064	GXD064
Tranter GX91	UFX-91	UFX-91 / GX-91 / GX91	GXD-091	GXD091
Tranter GX118	UFX-118	UFX-118 / GX-118 / GX118	GXD-118	GXD118
Tranter GC60	GC-60	GC-60 / GC60	GCP-060	GCP060
Tranter GX60	UFX-60	UFX-60 / GX-60 / GX60	GXD-060	GXD060
Tranter GX100	UFX-100	UFX-100 / GX-100 / GX100	GXD-100	GXD100
Tranter GX140	UFX-140	UFX-140 / GX-140 / GX140	GXD-140	GXD140
Tranter GX85	UFX-85	UFX-85 / GX-85 / GX85	GXD-085	GXD085
Tranter GX145	UFX-145	UFX-145 / GX-145 / GX145	GXD-145	GXD145
Tranter GX205	UFX-205	UFX-205 / GX-205 / GX205	GXD-205	GXD205
Tranter GX265	UFX-265	UFX-265 / GX-265 / GX265	GXD-265	GXD265
Tranter GF187	TW-18 / GF-187	TW-18 / GF-187 / GF187	GFP-187	GFP187

faq

What are the common model references for Tranter GXD-060 Gasket?

The Tranter GXD-060 gasket is commonly identified as:
Tranter GXD-060
Tranter GX-60
Tranter UFX-60
These model references are often used in spare parts searches.
Customers should confirm the original plate marking, gasket groove structure, and fixing method before ordering to avoid incorrect replacement.

What are the features of Tranter GXD-060 Gasket?

The Tranter GXD-060 Gasket belongs to the GX/GXD diagonal flow plate heat exchanger series.
Main functions include:
Plate edge and corner port sealing
Separation of hot and cold media
Supporting industrial heating and cooling applications
Reducing leakage caused by gasket aging
The gasket must match the original GXD-060 plate design.

Is Tranter GXD-060 Gasket interchangeable with GCP-060?

No.
Although GXD-060 and GCP-060 have similar model numbers, they are different Tranter plate configurations.
The GXD-060 uses a GX/GXD diagonal flow plate structure, while GCP-060 belongs to another plate design with different flow characteristics and gasket structure.
The gasket should be confirmed by plate model, groove design, and original gasket type.

Why choose Senovis PHE for Tranter GXD-060 replacement parts in UAE?

Senovis PHE provides:
Professional Tranter GXD-060 gasket and plate replacement solutions
Technical model verification support
Multiple gasket material options
International shipping assistance
Export documentation support
Senovis PHE helps global customers maintain Tranter Superchanger plate heat exchangers with reliable aftermarket gasket and plate solutions.

What is the Tranter GXD-060 Gasket?

The Tranter GXD-060 Gasket is a replacement sealing component designed for Tranter GXD-060 plate heat exchangers.
It is used for sealing plate edges and port areas, forming independent hot and cold fluid channels, and reducing leakage or media mixing risks during plate heat exchanger operation.
Senovis (Beijing) Technology Co., Ltd. (Senovis PHE) supplies Tranter GXD-060 Gaskets and Plates for industrial heat exchanger repair, refurbishment, and aftermarket maintenance projects.
