Sondex S188 Seawater Marine Plate Heat Exchanger Plates 1 2 3 4 Hole

DESCRIPTION

The Sondex S110 plate is a direct replacement for S110 and S110-IS frames, and one of the more technically distinctive options in the Sondex range. The fishbone plate pattern is worth noting — it’s not just a design detail. The geometry produces better flow distribution and lower pressure drop than standard corrugation patterns, which makes a practical difference in applications where pumping costs matter or where flow consistency across the plate pack is critical.

At SENOVIS PHE, we supply the S110 for maintenance, repair and refurbishment across HVAC, district heating, food and dairy processing, refrigeration, marine cooling, chemical processing, power generation and energy recovery. The S110 frame tends to appear in mid-to-large installations where thermal performance and pressure drop both matter — the fishbone pattern is part of why it gets specified in those situations.

Gasket options cover EPDM, NBR, HNBR and Viton — so whether you’re dealing with hot water circuits, refrigerants, oils or chemical media, there’s a compound that fits without overspecifying. If the frame is already open for a plate change, replacing gaskets at the same time is generally the more practical approach.

Compatibility extends to S100, S100B, S113, S121, S130 and S188 frames. If you’re managing multiple Sondex units on the same site, that cross-compatibility can reduce the number of different plate specs you need to keep on hand.

Sondex S110 Plate heat exchanger specification

Vicarb PHE Plate Heat Exchanger Replacemnet	Sondex S110
Corrugation Depth(mm)	2.6
Port Diameter(mm)	φ147
Chevron Angle	55° 135°
Corrugation Pitch(mm)	9 8.5
Equivalent Diameter	5.2
Flow Area(m²)	0.00118
One Plate (m²)	1.1
Port Distance (mm)	2094*296
Dimensions (mm)	2304*500

Actual Product Details

faq

What is the Sondex S188 plate heat exchanger?

The Sondex S188 is a large gasketed plate heat exchanger designed for demanding industrial heat transfer applications. It is widely used in district heating, power generation, marine engineering, HVAC systems, chemical processing, food manufacturing, sugar production, and other industries requiring high heat transfer efficiency, flexible capacity, and easy maintenance.

Can Senovis PHE supply replacement plates for the Sondex S188?

Yes. Senovis PHE manufactures compatible replacement plates for the Sondex S188 plate heat exchanger. Our plates are engineered to match the original plate profile, corrugation geometry, port layout, and gasket groove design, making them suitable for maintenance, refurbishment, and capacity restoration.

Does Senovis PHE provide replacement gaskets for the Sondex S188?

Yes. Senovis PHE supplies compatible Sondex S188 gaskets in several material options, including:
EPDM
NBR
HNBR
FKM (Viton)
Our engineering team can recommend the most suitable gasket material according to your operating media, temperature, pressure, and application.

How can I identify the correct Sondex S188 replacement plate?

For accurate identification, please provide:
Heat exchanger nameplate photo
Plate dimensions
Plate thickness
Plate corrugation pattern
Port hole configuration
Existing gasket style
Even if the original part number is unavailable, Senovis PHE can usually identify the correct compatible replacement based on these details.

Are Senovis PHE replacement parts compatible with the original Sondex S188?

Yes. Senovis PHE manufactures compatible replacement plates and gaskets for existing Sondex S188 plate heat exchangers. Before production, we verify the key dimensions and configuration using your nameplate information or plate sample to help ensure proper compatibility.

What materials are available for Sondex S188 plates?

Senovis PHE offers compatible Sondex S188 plates in multiple material grades, including:
SS304
SS316L
Titanium
SMO254
Nickel
Hastelloy (available upon request)
Material selection depends on corrosion resistance, process media, and operating conditions.
