GEA VT04 Cd 16 Flat Gea Ecoflex Plate Heat Exchanger
We manufacture plates for the GEA VT04 gasketed plate heat exchanger (GPHE), including gea vt04 cd 16 and gea ecoflex vt04 cd 16. With precise geometry and controlled production, our components ensure stable sealing and consistent thermal performance. Fully compatible with Alfa Laval, APV, TRANTER, sondex, GEA, Vicarb, API, Funke, thermowave, and Hisaka brands.
GEA VT04 details
PHE Model
GEA VT04 GPHE
Keyword
Sondex Heat
Applicable Industries
Liquid to liquid heat exchanging
Compatible Brands
Alfa Laval, GEA, Sondex, Tranter, APV, Kelvion, etc.
Tube material
SS304/SS316/SS316L
Plate Material
SS304,SS316,Titanium,Hastelloy,Nickle,Ti-pd
Function
Cooling Liquid
Medium
Saltwater
Usage
Refrigerating System Parts
DESCRIPTION
As a professional manufacturer of plate heat exchanger systems and components, we specialize in producing high-precision solutions for the GEA VT04 gasketed plate heat exchanger (GPHE). Our product range includes configurations such as gea vt04 cd 16 and gea ecoflex vt04 cd 16, designed with optimized plate geometry to support stable flow distribution and efficient thermal exchange. Each plate is manufactured using advanced pressing technology and strict quality control to ensure accurate dimensions and reliable sealing performance. With strong engineering experience and consistent production standards, we deliver dependable GPHE components that support long-term operational stability. Our products are fully compatible with Alfa Laval, APV, TRANTER, sondex, GEA, Vicarb, API, Funke, thermowave, and Hisaka brands, aligning with E-E-A-T principles for quality and trust.
APV A055 Plate heat exchanger specification
| PHE Plate Heat Exchanger Replacemnet | GEA VT04 PHE Plate Heat Exchanger |
| Keyword | Sondex Heat |
| Corrugation Depth(mm) | 2.55 |
| Port Diameter(mm) | φ32 |
| Chevron Angle | 128° |
| Corrugation Pitch(mm) | 11 |
| Equivalent Diameter | 5.1 |
| Flow Area(m²) | 0.00026 |
| One Plate (m²) | 0.04 |
| Port Distance (mm) | 480*61 |
| Dimensions (mm) | 550*129 |
Plate heat exchanger models Compatible Brands
| Compatible Brands | Plate heat exchanger models |
| Alfa Laval | M3, M6M, M10M, M10B, M15M, M15B, M20M(T20M) , T20B, T20P, M30, AK20, CLIP3, CLIP6, CLIP8, CLIP10, MX25B, MX25M, TS6M, TS20M, P16, P22/P26, TL6B, TL10B, TL10P, TL15B, A15B, M6MW, M10BW, MK15BW, T20MW, AM10, AM20, A20B, AX30B, AC400, AC600 |
| Sondex | S4A, S7A, S8A, S9A, S14A, S17, S18, S19A, S20A, S21, S21A, S22, S31A, S37, S38, S41A, S41, S42, S43, S47, S47A, S58, S62, S63, S64, S65, S81, S86, S100, S121, SW40, SF123 |
| APV | T4, SR1, SR2, SR3, SR9, R5, H12, H17, N25, N35, Q030D, Q030E, Q055D, Q055E, Q080E, SR6GL, K34, K55, A055, A085, J060, J092, J107, M60, M92, M107, B063, B110, B134 |
| GEA | VT04, VT10, VT20, VT20P, VT40, VT40M, VT80, VT80M, N40, VT405P, NT50T, NT50M,NT50X, NT100T, NT100M, NT100X, NT150S, NT150L, NT250S, NT250M, NT250L, NT350S, FA184 |
| API | SIGMA13, SIGMA19, SIGMA25, SIGMA26, SIGMA35, SIGMA35X, SIGMA37, SIGMA56, SIGMA66, SIGMA96, SIGMA106, SIGMA156 |
| FUNKE | FP04, FP08, FP09, FP10, FP14, FP16, FP19, FP20, FP22, FP205, FP31, FP40, FP41, FP50, FP60, FP80, FP81, FP100, FP120, FP405 |
| Tranter | GC8, GX26, GC51, GX64, GX145, GL13, GX42, GX51, GX85, GL16, GCD044, GC60, GX91, GC26, GCD054, GX60, GX100 |
| Vicarb | V2, V4,V8, V13, V20, V28, V45, V60, V85, , V100, V110, V130 |
| Thermowave | TL90SS, TL90PP, TL150SS, TL150PP, TL250SS, TL250PP, TL400SS, TL400PP, TL500SS, TL500PP, TL650SS, TL650PP |
| SWEP | C8, GX12, GL13, GC16, GX26, GC26, GX42, GC51, GX51, GC60, GX60, GX64, GX85, GX91, GX100, GX145, GX180 |
Workshop of Plate Heat Exchanger Factory
