| Keyword | Alfa Laval Brazed Plate Heat Exchanger BPHE |
| Plate Number | 10 – 250 |
| Thickness A (mm) | 12 + (2.7 × n) mm |
| Dimension LWH (mm) | 415 × 1012 × A mm |
| Center Distance (mm) | 272 mm / 864 mm |
| Weight (kg) | 28 + (1.35 × n) kg |
| Volume (L) Q1Q2 Side / Q3Q4 Side | 1.14 L / 1.14 L per channel |
| Designed Pressure | Max 30 bar (depending on version) |
| Designed Temperature | -196°C ~ +225°C |
| Plate Materials | Stainless Steel 316L / Copper Brazing |
| Capacity | Up to 7500 kW |
Operating Parameters
| Parameter | Value |
| Max Operating Temperature | 80°C |
| Hot Side Inlet | 70°C |
| Hot Side Outlet | 60°C |
| Cold Side Outlet | 50°C |
| Cold Side Inlet | 40°C |
| Design Ambient Temperature | 30°C |
| Min Inlet Temperature | 20°C |
Key Features
① Vacuum-Brazed Construction All plates are permanently bonded through a high-temperature vacuum copper brazing process — eliminating gaskets, preventing leakage, and withstanding operating pressures up to 3.0 MPa.
② Superior Heat Transfer Efficiency The asymmetric corrugated plate geometry creates turbulent flow at low Reynolds numbers, achieving thermal effectiveness up to 99% with a minimum approach temperature of just 1°C.
③ Ultra-Compact Design Delivers the same thermal capacity as a shell-and-tube heat exchanger at just 1/5 the size and weight — reducing installation space, piping costs, and structural load.
④ 316L Stainless Steel Plates Corrosion-resistant cold-rolled stainless steel construction ensures compatibility with water, glycol solutions, refrigerants (R410A, R32, R134a), and food-grade fluids.
⑤ True Counterflow Configuration Diagonal flow port design achieves genuine counterflow heat exchange, maximizing the log mean temperature difference (LMTD) and driving down energy consumption.
⑥ Maintenance-Free Operation No gaskets, no moving parts. The fully brazed structure requires zero routine maintenance and delivers a service life exceeding 20 years under normal operating conditions.
Applications
- 🔵 HVAC Systems — Fan coil units, heat pumps, district heating substations
- 🔵 Industrial Refrigeration — Evaporators, condensers, economizers
- 🔵 Renewable Energy — Solar thermal, geothermal heat pump circuits
- 🔵 Industrial Process — Oil cooling, hydraulic system cooling, machine tool cooling
- 🔵 Domestic Hot Water — Instantaneous water heaters, boiler systems
Why Choose Alfa Laval CB300?
“When installation space is limited but thermal performance cannot be compromised, the CB300 is the answer.”
The CB300 combines Alfa Laval’s decades of plate heat exchanger expertise with a robust, field-proven design trusted by engineers across 100+ countries. Whether retrofitting an existing system or specifying for a new build, the CB300 offers unmatched value in efficiency, reliability, and total cost of ownership.
Direct Contact Channels:
Reduce your maintenance costs with SENOVIS PHE ! As a specialized factory for GPHE, BPHE, plates, and gaskets, we offer 100% interchangeable solutions for Alfa Laval, APV, Tranter, Sondex, GEA, and more. Click “Contact Us” to request a quick quote and premium catalog now!
